1050 Aluminium

1050 Aluminium is a commercially pure wrought aluminium grade containing a minimum of 99.5% aluminium. It provides excellent corrosion resistance, high electrical and thermal conductivity, good weldability and very good forming characteristics. The material is commonly selected for components that require bending, deep drawing, spinning, pressing or fabrication rather than high mechanical strength.

Solitaire Steel & Engineering LLP, based in Khetwadi, Mumbai, India, supplies and exports 1050 aluminium sheets, plates, coils, circles, pipes, tubes, round bars, flat bars, wire coils and other required forms. Material can be supplied in applicable tempers, standards, dimensions and finishes according to the buyer’s drawing, application and quantity.

Table of Contents

Send Enquiry whatsapp

Call Us

+91 9819046580

Email Us

info@solitairesteelllp.com

Technical Specifications of 1050 Aluminium

Physical Properties

Property Typical Value
Density 2.71 g/cm³
Melting Range Approximately 646°C–657°C
Modulus of Elasticity Approximately 69–71 GPa
Poisson’s Ratio Approximately 0.33
Thermal Expansion Approximately 23.5–24 × 10⁻⁶/°C
Electrical Resistivity Approximately 0.0282 Ω·mm²/m

Physical values are typical and may vary slightly with product form, temper and governing specification.

Mechanical Properties

Property Typical Value for H14 Sheet
0.2% Proof Strength 85 MPa minimum
Tensile Strength 105–145 MPa
Elongation 12% minimum
Brinell Hardness Approximately 34 HB
Strengthening Method Cold working

Mechanical properties change with temper, thickness and product form. Buyers should specify the required temper and mechanical-property limits in their enquiry.

Electrical Properties

Property Typical Value
Electrical Conductivity Approximately 60–61% IACS
Electrical Resistivity Approximately 0.0282 µΩ·m
Suitability Conductive parts, busbars and electrical components

Optical Properties

Property Performance
Surface Reflectivity High when supplied with a suitable bright or polished finish
Anodising Response Good
Decorative Finish Suitability Suitable for reflectors, panels and architectural components
Surface Finish Options Mill finish, polished, brushed or as required

Reflectivity depends on surface condition, finish, fabrication and subsequent treatment.

Thermal Properties

Property Typical Value
Thermal Conductivity Approximately 222 W/m·K
Specific Heat Capacity Approximately 0.90 J/g·K
Melting Range Approximately 646°C–657°C
Thermal Expansion Coefficient Approximately 23.5–24 µm/m·K

Processing Properties

Property Performance
Cold Formability Excellent
Deep Drawing Excellent in a suitable temper
Weldability Excellent
Brazability Good
Machinability Fair
Corrosion Resistance Excellent
Anodising Ability Good
Heat-Treatable No
Strengthening Method Strain hardening or cold working

Chemical Composition

Element Composition (%)
Aluminium (Al) 99.50% minimum
Silicon (Si) 0.25% maximum
Iron (Fe) 0.40% maximum
Copper (Cu) 0.05% maximum
Manganese (Mn) 0.05% maximum
Magnesium (Mg) 0.05% maximum
Zinc (Zn) 0.07% maximum
Titanium (Ti) 0.05% maximum
Other Elements—Each 0.03% maximum
Other Elements—Total 0.10% maximum

Chemical limits should be confirmed against the applicable material specification and the supplied material test certificate.

1050 Aluminium Product Range by Solitaire Steel & Engineering LLP

Product Applicable Standard Available Type Size Availability Common Applications
Sheets ASTM B209 / EN 485 O, H12, H14, H16, H18 and required tempers Standard and customised thicknesses, widths and lengths General fabrication, cladding, reflectors and electrical components
Plates ASTM B209 / EN 485 Mill finish, cut-to-size and fabricated Standard and customised dimensions Equipment panels, chemical equipment and general engineering
Coils and Strips ASTM B209 / EN 485 Slit coil, mill finish, polished and coated Required thickness, width and coil quantity Cable sheathing, packaging, insulation and formed components
Circles and Discs ASTM B209 / EN 485 Plain, cut-to-size and deep-drawing quality Required diameter and thickness Cookware, utensils, lighting and spun components
Chequered Plates ASTM B209 Patterned plate in required temper Standard and customised dimensions Flooring, access panels and fabricated surfaces
Pipes ASTM B241/B241M Seamless, extruded or as required Standard and customised OD, wall and length Process lines, lightweight fabricated systems and general engineering
Tubes ASTM B210/B210M or applicable specification Drawn, seamless, extruded or as required Standard and customised OD, wall and length Heat-transfer equipment, fabricated assemblies and electrical applications
Round Bars ASTM B221/B221M Extruded or drawn Standard and customised diameters and lengths Electrical parts, turned components and general fabrication
Flat Bars ASTM B221/B221M Extruded, slit or cut from plate Required width, thickness and length Busbars, conductive parts, supports and fabricated components
Wire and Wire Coils ASTM B211/B211M or applicable specification Straight wire or coil Required diameter and coil quantity Electrical, fastening and forming applications

Availability depends on the required product form, temper, standard, dimensions, finish and order quantity. Submit the complete specification for confirmation.

Applications of 1050 Aluminium

  • Electrical Equipment: Used for busbars, conductive strips, electrical panels, cable sheathing and components requiring good electrical conductivity.
  • Chemical Processing: Suitable for tanks, equipment parts, trays and fabricated components exposed to general corrosive environments.
  • Heat-Transfer Equipment: Used for fins, heat-transfer components, heat shields and equipment requiring good thermal conductivity.
  • Food-Industry Equipment: Used for containers, trays, utensils and fabricated components where the selected specification is suitable for the intended service.
  • Lighting and Reflectors: Its bright surface and reflectivity make it suitable for lamp reflectors, lighting fixtures and decorative components.
  • Architectural Fabrication: Used for flashings, cladding parts, roofing accessories, fascia, panels and decorative metalwork.
  • General Sheet-Metal Work: Suitable for bending, pressing, spinning, deep drawing and other fabrication processes.
  • Packaging and Insulation: Used for closures, containers, protective coverings, insulation jacketing and formed packaging components.

When Should a Buyer Select 1050 Aluminium?

1050 aluminium is a suitable choice when the requirement prioritises corrosion resistance, conductivity, surface finish and formability over high mechanical strength. It is particularly useful for deeply formed, bent, spun, welded or conductive components.

Buyers requiring higher structural strength, improved machining performance or heavily loaded components should discuss grades such as 2014, 6061, 6082 or 7075 with the Solitaire Steel & Engineering LLP sales team before ordering.

Information Required for a 1050 Aluminium Quotation

For an accurate quotation and material recommendation, please provide:

  • Required product form
  • 1050 or 1050A designation
  • Applicable ASTM, EN, BS, DIN, JIS or other standard
  • Required temper, such as O or H14
  • Thickness, width, length, diameter or wall thickness
  • Surface finish
  • Cutting or fabrication requirement
  • Quantity or total weight
  • Material test certificate requirement
  • Inspection requirement
  • Delivery location
  • Required delivery schedule

For a quotation for 1050 aluminium sheets, plates, coils, circles, pipes, tubes, bars or other product forms, contact Solitaire Steel & Engineering LLP. Our team will review your required standard, temper, dimensions, application, quantity and delivery location before confirming availability and pricing.

❝

For a free quote or to learn more about our range of Aluminium Sheets and Plates, Contact Solitaire Steel & Engineering LLP today. Our team is ready to assist with tailored solutions for all your industrial needs.

❞
